13. EXPLODED VIEW & REPLACEMENT PART LIST
- 198 -
Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
Level LocationNo. Description PartNumber Spec Remark
6 CN5001 Connector,BtoB ENBY0036001
GB042-40S-H10-E3000 40P 0.4MM STRAIGHT
SOCKET SMD R/TP 1M ENGINEERING PLASTIC
UL94V-0 AU OVER NI LS Mtron Ltd.
6 U9000 IC,Bluetooth EAN62732401
WCN-2243-0-58BWLNSP-TR-06-0 Die
revison(CS2), BT4.0 DM+FM Tx/Rx, 3.3x3.22x0.63
WLCSP R/TP 58P QUALCOMM
INCORPORATED.
6
C1079
C1092
Capacitor
Ceramic,Chip
ECCH0000183
GRM1555C1H1R8C 1.8pF 0.25PF 50V NP0 -
55TO+125C 1005 R/TP - MURATA
MANUFACTURING CO.,LTD.
6 CN4000 Connector,I/O EAG63511101
3.2.01.0146 5P 0.90MM STRAIGHT RECEPTACLE
SMD T/REEL - SHENZHEN EVERWIN
PRECISION TECHNOLOGY CO.,LTD.
6 R3013 Resistor,Chip ERHZ0000486
MCR01MZP5J473 47KOHM 5% 1/16W 1005 R/TP
- ROHM.
6 FB9000 Filter,Bead EAM62471001
BLM03AX241SN1D 240 ohm 0.6X0.3X0.33 25%
0.38 ohm 0.35A SMD R/TP 2P 0 MURATA
MANUFACTURING CO.,LTD.
6 L1011
Inductor
Multilayer,Chip
ELCH0001408
LL1005-FHL6N8J 6.8NH 5% - 300mA 0.23OHM
5.6GHZ 9 SHIELD NONE 1.0X0.5X0.5MM R/TP
TOKO, INC.
6
C9008
Capacitor(High
Frequency),Cerami
EAE62963601
GRM1555C1H100J_H 10pF 5% 50V C0G -
55TO+125C 1005 R/TP 0.5+/-0.05 L:1.0+-0.05
W 0 5 0 05 T 0 5 0 05 MURATA
6
C9008
Frequency),Cerami
c,Chip
EAE62963601
W
:
0
.
5
+-
0
.
05 T
:
0
.
5
+-
0
.
05 MURATA
MANUFACTURING CO.,LTD.
6 R9008 Resistor,Chip ERHZ0000203
MCR01MZP5F1002 10KOHM 1% 1/16W 1005
R/TP - ROHM.
6 CN7001 Jack,Phone EAG63070601
KJA-PH-4-0176 5P 2P ANGLE R/TP 3.5M BLACK
5P - KSD CO., LTD
6 R2004 Resistor,Chip ERHZ0000206
MCR01MZP5F10R0 10OHM 1% 1/16W 1005 R/TP
- ROHM.
6 SW1000 Connector,RF ENWY0008701
MS-156C NONE STRAIGHT SOCKET SMD
T/REEL AU 50OHM 400mDB HIROSE KOREA
CO.,LTD
6 FL1002 Filter,Saw,Dual EAM62671401
SFRG42MB002 1960/1842MHz 1.5*1.1*0.55 SMD
R/TP 10P WISOL.CO.,LTD
