13. EXPLODED VIEW & REPLACEMENT PART LIST
- 199 -
Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
Level LocationNo. Description PartNumber Spec Remark
6 R2008 Resistor,Chip ERHZ0000291
MCR01MZP5F49R9 49.9OHM 1% 1/16W 1005
R/TP - ROHM.
5 EBR071700
PCB Assembly
Main,SMT Top
EBR77394601 LGE410.ACISBK 1.0 Main
6
C3004
C3006
C3007
C3008
C3009
C3017
C3018
C3019
C3020
C3023
C4043
C4044
C4049
C4050
C4051
C4052
C4053
C4054
C4055
C4056
C4057
C4058
C4059
C4060
C4061
C4072
C5000
Capacitor
Ceramic,Chip
ECCH0004904
GRM155R60J105K 1uF 10% 6.3V X5R -55TO+85C
1005 R/TP - MURATA MANUFACTURING
CO.,LTD.
C5005
C6005
C9024
6 EAX010000 PCB,Main EAX65291401 LGE410G.ATCLBK 1.0 FR-4 SBL 8 0.8T Main
6 L7002
Inductor
Multilayer,Chip
ELCH0001444
0402AF-101XJEW 100NH 5% - 900mA 0.16OHM
1.4GHZ 8 NON SHIELD NONE 1.12X0.66X0.66MM
R/TP COILCRAFT SINGAPORE PTE LTD.
6
R1023
R4021
R4023
Resistor,Chip ERHZ0000348
MCR01MZP5F12R0 12OHM 1% 1/16W 1005 R/TP
- ROHM.
