13. EXPLODED VIEW & REPLACEMENT PART LIST
- 201 -
Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
Level LocationNo. Description PartNumber Spec Remark
6
C1018
C1054
C7022
L1039
Capacitor
Ceramic,Chip
ECZH0000830
C1005C0G1H330JT000F 33pF 5% 50V NP0 -
55TO+125C 1005 R/TP - TDK KOREA
COOPERATION
6 R8008 Resistor,Chip ERHZ0000402
MCR01MZP5J100 10OHM 5% 1/16W 1005 R/TP -
ROHM.
6 U4002 IC,Mini ABB EAN62112401
RT8966AGQW RT8966A 1.65~5.5V 60uA
SWITCH/MULTIPLEXER QFN R/TP 32P Mini ABB
MUIC, Charger IC, Current Sink 4Ch, LDO 4Ch
RICHTEK TECHNOLOGY CORP. QFN R/TP 32P
RICHTEK TECHNOLOGY CORP.
6
C3005
C3010
C3016
C3021
C3022
C4040
C4041
C4045
C4046
C4047
C4048
C4069
C4070
C5002
C5003
C9033
C9041
Capacitor
Ceramic,Chip
ECCH0000198
CL05A225MQ5NSNC 2.2uF 20% 6.3V X5R -
55TO+85C 1005 R/TP . SAMSUNG ELECTRO-
MECHANICS CO., LTD.
6
VA5000
VA5005
VA8016
VA8017
VA8018
Varistor SEVY0001001
EVLC14S02050 14V 0% 50F 1.0*0.5*0.6 NONE
SMD R/TP AMOTECH CO., LTD.
6 CN6000
Connector
Terminal Block
EAG63510601
BM26C1.4-6DCP-1.6V 6P 1.78MM STRAIGHT
SMD T/REEL - HIROSE KOREA CO.,LTD
6
ZD6001
ZD6002
ZD6003
Diode,TVS EDTY0012501
UCLAMP3311T.TCT 3.3V 3.5V min. 6.5V 5A -
SLP1006P2T R/TP 2P 1 SEMTECH
CORPORATION
6
R2007
R2013
R2016
R3009
R4026
Resistor,Chip ERHZ0000405
MCR01MZP5J103 10KOHM 5% 1/16W 1005 R/TP
- ROHM.
