13. EXPLODED VIEW & REPLACEMENT PART LIST
- 202 -
Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
Level LocationNo. Description PartNumber Spec Remark
6
R2003
R7007
R7008
Resistor,Chip ERHY0003301
MCR01MZP5J101 100OHM 5% 1/16W 1005 R/TP -
ROHM.
6
R1000
R1001
R4019
R5005
R5006
R5007
R5008
R6009
R7026
R9007
R9009
R9010
PCB ASSY,MAIN
PAD SHORT
SAFP0000401 LG-LU3000 LGTBK,MAIN,A,
6 R8007 Resistor,Chip ERHZ0000288
MCR01MZP5F4703 470KOHM 1% 1/16W 1005
R/TP - ROHM.
6 C7008
Capacitor
Ceramic,Chip
ECCH0000112
MCH155C150J 15pF 5% 50V NP0 -55TO+125C
1005 R/TP - ROHM Semiconductor KOREA
CORPORATION
6 ZD7000 Diode,TVS EDTY0010101
ESD9B5.0ST5G 5V 5.8V min. 12.5V 1A - SOD-923
R/TP 2P 1 SCG HONG KONG SAR LTD.
6 VA7007 Varistor SEVY0010501
IECS0505C040FR 10V 0% 4E-12F 1.0x0.5x0.3
IEC61000-4-1 (ESD) level #4 SMD R/TP
INNOCHIPS TECHNOLOGY
4
EBR071500
PCB Assembly
EBR77394501
LGE410 ACISBK 1 0 Main
4
EBR071500
Main,Insert
EBR77394501
LGE410
.
ACISBK 1
.
0 Main
5 EBP01 Camera Module EBP61842201
CW2044 CW2044 2M FF, TSB(1/5"), 7x7x4.1,
FPCB, 90deg., MIPI COWELL ELECTRONICS
CO.,LTD
5 RAA050100 Resin,PC BRAH0001301 UF2040 or 3075BHF . . NONE
2 EAD010000 Cable,Assembly EAD62377901
IFS00015 USB USB 1.0M 4 BLACK UL N
INTERFACESAMIL CO.,LTD
