6-1 CONTROL PANEL AND REMOTE
POWER ON/OFF
Turns the air conditioner on and off. When turning on,
a rising tone will sound to confirm. When turning off,
a descending tone will sound.
AUTO CLEAN
The AUTO CLEAN function is used to remove
moisture from the heat exchangers and helps
prevent odor from forming. This function can be
activated from the Remote only.
FAN SPEED
Adjusts the circulation fan speed between low (F1),
medium (F2), and high (F3).
MODE
Switches the air conditioner between COOL, FAN,DRY,
ENERGY SAVE modes.The
active mode will be
A PART
shows the set temperature ( or ) ,
fan speed, or the selected TIMER delay.
B PART shows the active mode(COOL,FAN,DRY,ENERGY
SAVER and HEAT
),Auto clean,Water full and Timer.
/ (TEMP/TIMER)
Use these buttons to adjust the set temperature up or
down, or to adjust the timer delay time.
TIMER
Allows you to set a delay from 1 to 24 hours that will
turn the air conditioner on or off automatical ly.
5
1
4
9
2
7
6
3
8
Operation of functions is the same when using the remote or the
control panel, unless otherwise stated.
For detailed instructions on each function, see the following pages
!
AUTO SWING
Sets the motorized air discharge to oscillate,
improving air circulation in the room. This function
K
control.
an only be activated and displayed from the remote
shown in the LCD display.
LED DISPLAY
B PART
A PART
6
1
3
4
5
7
6
5
Use this button,the temperature display can be switched
between degrees Celsius(°C) and degrees Fahrenheit(°F)
