4-3 WINDOW VENT PANEL AND EXTENSIONS
The window installation kit allows you to install the air conditioner in most vertical-sliding windows
18" to 50" wide, or casement-style windows from 18" to 50 " high.
For an 18" window opening, use the window
vent panel by itself.
For window openings from 19" to 26",
use the window vent panel (Panel A) and a
extension panel (Panel B).
use the window vent panel (Panel A) and a
extension panel (Panel C).
eht esu ,"05 ot " 53 morf sgninepo wodniw roF
window vent panel and two extension panels
(Panel C and Panel D).
Panel A
Panel A
18"
18"
Panel A
19" − 26"
19" − 26"
Panel B
Panel A
Fig. “a”
Fig. “b”
27"−34"
Fig. “c”
Fig. “d”
3 ot " 72 morf sgninepo wodniw roF4",
ABCD
18" 9" 17" 17"
18"
Ĝ
a
19" − 26"
ĜĜ
b
ĜĜ
c
Ĝ
d
Fig.
Panel
Window Length
ĜĜ
1. Please check your window length and choose the
fit panels from the above tabel.
2. If your window length need more than 2 panels, after
adjust the length, please use type A screw to fix them.
Panel D
Panel A
Panel C
Panel A
Panel C
Panel D
Panel A
Panel C
Screw A
27" − 34"
35" − 50"
27"−34"
35"−50"
35"−50"
Window Installation Kit (includes 1 Window
Vent Panel and 3 Extension Panels)
Panel A (18’’)
Panel C (17’’)
Panel D (17’’)
Panel B (9’’)
1 Window Vent Panel
3 Extension Panels
Panel B
Panel A
Panel C
To Next Page
