LG LP1415GXR - Component Testing Imformation; Transformer

- 42 -
Copyright ©2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
Wring diagram
Test point
Result
12 3 4
Test points Result
˄
1
˅
to
˄
2
˅
120
¡

300
¡
˄
25
ć
˅
˄
3
˅
to
˄
4
˅
1.5
¡

5
¡
˄
25
ć
˅
10-1 Transformer
10. COMPONENT TESTING IMFORMATION
