- 32 -
Copyright ©2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
Display PCB
8-2 PCB picture
Connect the
Transformer
output
Main PCB
Connect the water
pump motor
Connect the
transformer input
Connect the
Display PCB
Connect the
Temp sensor
Connect the
down pump
Connect the
Lever switch
Connect the
4-way valve
Connect the
Down motor
Connect the
up motor
8. CIRCUIT DIAGRAM
