ENGLISH
39
CARE AND CLEANING
Replacing the oven door
1. Firmly grasp both sides of the door at the top.
Hinge arm
Indentation
Bottom edge
of slot
2. With the door at the same angle as the removal
position, seat the indentation of the hinge arm into
the bottom edge of the hinge slot. The notch in the
hinge arm must be fully seated into the bottom of
the slot.
Hinge lock
Hinge arm
Slot
Door frame
3. Fully open the door. If the door will not fully open,
the indentation is not seated correctly in the bottom
edge of the slot.
4. Push the hinge locks down against the front frame
of the oven cavity to the locked position. Close the
oven door.
REMOVING AND REPLACING THE
OVEN DOOR AND DRAWER
• The door is very heavy. Be careful when removing
and lifting the door.
• DO NOT lift the door by the handle.
• DO NOT hit the glass with pots, pans, or any other
object.
• Scratching, hitting, jarring or stressing the glass
may weaken its structure, causing an increased risk
of breakage at a later time.
CAUTION
Removing the oven door
1. Fully open the door. Pull the hinge locks down
toward the door frame, to the unlocked position. A
tool, such as a small at-blade screwdriver, may be
required.
Slot
Hinge lock
Hinge arm
Door frame
2. Firmly grasp both sides of the door at the top.
Close the door to the removal position (approxi-
mately ve degrees) which is halfway between the
broil stop position and fully closed.
3. Lift the door up and out until the hinge arm is clear
of the slot. Put the door on the oor.
Push hinge locks down to unlock
Push hinge locks up to lock
About 5˚
Removal Position
