FAILURE CODE SUMMARY
Code Description How to detect Check point
F1
F2
F3
F6
F9
F10
Sensor open
Sensor short
Button short
Oven hot
Oven
No heating
Door Lock Fail
Oven Thermistor is open
Oven Thermistor is short
When some button is continuously short for >= 60
seconds.
The oven temperature is over 650 ˚F continuously
during 2 minutes on cooking except self cleaning.
EXCEPT PROOF and WARM
Case 1: start temperature does not exceed 130 ˚F and
oven temperature is less equal than 150 ˚F and max
oven temperature is less equal than start oven temp.
Case 2: oven temperature is less equal than 100 ˚F
over 5 minutes on preheating.
In case of Door Lock Failure in operating Lock motor.
1. Wiring
2. Oven Sensor
1. Wiring
2. Oven Sensor
1. Wiring
2. KeyPad(in case of
Key Pad Model )
Oven Sensor
1. Electric Wiring
2. Oven Sensor
1. Electric Wiring
2. Motor’s Resistance
3. Micro Switch
