32 | PRODUCT DATA
Single Zone Mega, Standard E󰀩ciency, and Mega 115V Wall Mounted Engineering Manual
Due to our policy of continuous product innovation, some specications may change without notication.
© LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG ” is a registered trademark of LG Corp.
OUTDOOR UNIT WIRING DIAGRAM
Mega 115V Models
Wiring Diagram for LSU090HXV2 and LSU120HXV2
MEZ63959335_Rev.00
Option
Field Wiring
Factory Wiring
CN_FAN_DC
WCN-P(L)
CN-COM
RD
YL
BL
Outdoor PWB ASSY
REVERSING VALVE
BK
BK
CN2
CN3
SURGE
ABSORBER
250 V / T20 A
WCN-P(N)
CN_4WAY_AC
CN_TH1
CN_TH2
CN_EEV1
D-PIPE
A 51.3T / V 052
BK BK
Connverter
A 51.3T / V 052
TERMINAL BLOCK
BR
BL
RD
GN/YL
CN_LGMV
MVC JIG
CN_COIL1
CN_COIL2
250 V / T20 A
GN/YL
2(L2) 31(L1) 2(L2)1(L1)
RY_4WAY_AC
POWER TO INDOOR UNIT
REACTOR
OUTDOOR
TH.
PIPE TH.
USE COPPER CONDUCTORS ONLY
BR
BL
RD
U
W
V
CN_COMP
7/19
