60 | PERFORMANCE DATA
Single Zone Mega, Standard Eciency, and Mega 115V Wall Mounted Engineering Manual
PERFORMANCE DATA
Cooling Capacity
Outdoor
Air
Temp.
(°F DB)
Indoor Air Temperature (°F DB / °F WB)
64 / 53 68 / 57 72 / 61 77 / 64 80 / 67 86 / 72 90 / 75
TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
4 5.51 4.90 0.31 6.89 5.21 0.37 8.27 5.53 0.43 9.99 5.93 0.50 11.03 6.17 0.54 9.20 6.72 0.44 7.99 7.10 0.37
23 5.92 5.26 0.31 7.12 5.60 0.37 8.32 5.94 0.44 9.82 6.36 0.52 10.72 6.62 0.57 9.43 7.22 0.45 8.57 7.62 0.37
25 6.01 5.34 0.32 7.18 5.67 0.38 8.36 6.00 0.44 9.83 6.41 0.52 10.71 6.66 0.57 9.54 7.30 0.46 8.75 7.72 0.39
30 6.24 5.55 0.34 7.35 5.85 0.40 8.46 6.16 0.46 9.85 6.54 0.53 10.68 6.77 0.57 9.80 7.49 0.48 9.20 7.97 0.41
35 6.47 5.75 0.36 7.52 6.03 0.42 8.56 6.31 0.47 9.87 6.66 0.54 10.66 6.87 0.58 10.05 7.69 0.49 9.65 8.23 0.44
40 6.70 5.96 0.39 7.69 6.22 0.43 8.67 6.47 0.48 9.90 6.79 0.54 10.63 6.98 0.58 10.31 7.88 0.51 10.10 8.48 0.47
45 6.94 6.17 0.41 7.85 6.40 0.45 8.77 6.63 0.50 9.92 6.92 0.55 10.61 7.09 0.59 10.57 8.07 0.53 10.55 8.73 0.50
50 7.17 6.37 0.43 8.02 6.58 0.47 8.88 6.78 0.51 9.94 7.04 0.56 10.58 7.19 0.59 10.83 8.27 0.55 11.00 8.98 0.52
55 7.40 6.58 0.46 8.19 6.76 0.49 8.98 6.94 0.52 9.96 7.17 0.57 10.56 7.30 0.59 11.09 8.46 0.57 11.45 9.23 0.55
60 7.63 6.79 0.48 8.36 6.94 0.51 9.08 7.10 0.54 9.99 7.29 0.58 10.53 7.41 0.60 11.35 8.66 0.59 11.90 9.49 0.58
65 7.56 6.72 0.50 8.25 6.91 0.53 8.94 7.10 0.56 9.80 7.34 0.60 10.31 7.48 0.62 11.13 8.66 0.61 11.68 9.45 0.61
70 7.49 6.66 0.53 8.14 6.88 0.55 8.79 7.11 0.58 9.61 7.39 0.62 10.09 7.55 0.64 10.91 8.67 0.64 11.46 9.41 0.64
75 7.43 6.60 0.55 8.04 6.86 0.58 8.65 7.11 0.60 9.42 7.43 0.64 9.87 7.62 0.66 10.69 8.67 0.66 11.24 9.37 0.67
80 7.36 6.54 0.58 7.93 6.83 0.60 8.51 7.12 0.63 9.22 7.48 0.66 9.66 7.70 0.67 10.48 8.68 0.69 11.02 9.33 0.70
85 7.29 6.48 0.60 7.82 6.80 0.62 8.36 7.12 0.65 9.03 7.53 0.68 9.44 7.77 0.69 10.26 8.68 0.71 10.80 9.29 0.73
90 7.22 6.42 0.62 7.72 6.77 0.65 8.22 7.13 0.67 8.84 7.57 0.70 9.22 7.84 0.71 10.04 8.69 0.74 10.58 9.25 0.76
95 7.15 6.36 0.65 7.61 6.74 0.67 8.07 7.13 0.69 8.65 7.62 0.72 9.00 7.91 0.73 9.82 8.69 0.76 10.36 9.21 0.79
100 6.96 6.19 0.66 7.43 6.60 0.68 7.91 7.00 0.70 8.50 7.51 0.73 8.86 7.82 0.74 9.65 8.55 0.78 10.17 9.04 0.80
105 6.77 6.02 0.67 7.26 6.45 0.69 7.75 6.87 0.71 8.35 7.40 0.74 8.72 7.72 0.75 9.48 8.41 0.79 9.99 8.88 0.81
110 6.59 5.85 0.68 7.08 6.30 0.70 7.58 6.74 0.72 8.21 7.29 0.75 8.58 7.63 0.77 9.31 8.28 0.80 9.80 8.71 0.82
115 6.35 5.65 0.69 6.83 6.08 0.71 7.32 6.51 0.73 7.92 7.05 0.76 8.28 7.37 0.77 8.99 8.00 0.81 9.47 8.42 0.83
118 6.21 5.52 0.69 6.68 5.94 0.71 7.16 6.37 0.73 7.75 6.90 0.76 8.10 7.21 0.78 8.80 7.83 0.81 9.27 8.24 0.84
122 6.02 5.63 0.70 6.48 6.06 0.72 6.94 6.49 0.74 7.51 7.03 0.77 7.86 7.36 0.79 8.54 7.99 0.82 8.99 8.40 0.84
Table 24: LSN090HXV2 / LSU090HXV2 Cooling Capacities.
Cooling Capacity Table for LS090HXV2 (LSU090HXV2 + LSN090HXV2)
DB: Dry Bulb Temperature (°F) WB: Wet Bulb Temperature (°F) TC: Total Capacity (kBtu/h)
SHC: Sensible Capacity (kBtu/h) PI: Power Input (kW) (includes compressor, indoor fan motor and
outdoor fan motor)
1. All capacities are net, evaporator fan motor heat is deducted.
2. Grey shading indicates reference data. When operating at this temperature, these values can be
different if the system is not running consistently..
3. Direct interpolation is permissible. Do not extrapolate.
Capacity as rated: 0 ft. above sea level with 24.6 ft. of refrigerant piping. 0 ft. level difference between
outdoor and indoor units.
Cooling capacity rating obtained with air entering the indoor unit at 80ºF dry bulb (DB) and 67ºF wet
bulb (WB), and outdoor ambient conditions of 95ºF dry bulb (DB) and 75ºF wet bulb (WB).
