ELECTRICAL DATA

Table 3: Single Zone High Efciency Standard Wall Mount System Electrical Data.

Electrical Data

Nominal

Tons

Unit Model No. Hertz Voltage

Voltage

Range

(Min. to Max.)

MCA MOP

Compressor

Quantity

Compressor Motor

RLA

Outdoor Fan Motor

Indoor

Fan Motor

Cooling Heating

kW FLA FLA

3/4 LS090HSV5

60 208 - 230 187 - 253

10.0 15.0 1 7.0 7.0 0.043 0.4 0.4

1 LS120HSV5 10.0 15.0 1 7.0 7.0 0.043 0.4 0.4

1-1/2 LS180HSV5 13.0 20.0 1 9.6 9.6 0.124 0.25 0.4

Voltage tolerance is ±10%.

Maximum allowable voltage unbalance is 2%.

MCA = Minimum Circuit Ampacity.

Maximum Overcurrent Protection (MOP) is calculated as follows:

(Largest motor FLA x 2.25) + (Sum of other motor FLA) rounded

down to the nearest standard fuse size.

RLA = Rated Load Amps.

FLA = Full Load Amps.
