LG LS090HSV5 Engineering Manual

PRODUCT DATA | 13
Product Data
Due to our policy of continuous product innovation, some specications may change without notication.
©
LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
OUTDOOR UNIT DIMENSIONS
LSU090HSV5, LSU120HSV5
Unit : Inch (mm)
4-3/16 (106)
31/32 (24)
10-1/2(267)
19/32 (15)
21-1/2 (545)
4-15/16 (125)
6-7/16 (163)
5-3/32 (129)
1-7/32 (30.5)
12-1/16 (306)
9-5/16 (236)
30-5/16 (770)
10-29/32 (277)
Ø17-11/32 (440)
2-23/32 (69)
15/32 (11.5)
11-5/16 (288)
13/16 (20)
25°
25°
2-3/32 (54)
22 (558)
12-31/32 (330)
13-29/32 (353)
Drain Hole 8-Ø13/16 (20)
Liquid Pipe
Connection
(Flared)
Vapor Pipe
Connection
(Flared)
Sump Heater
Service Valve Cover
Communication /
Connection
(Power)
Cable Hole
Control Box
Air Outlet

LG LS090HSV5 Specifications

General

Brand	LG
Model	LS090HSV5
Category	Air Conditioner
Language	English
