LG LSE4617ST User Manual

9-28
CHECKING FLOW CHART BY FAILURE
Symptom Check Point
CF7(IH Left comm. Error)
(open/short)
1. Check the CN71 Connect
Yes
Reconnect
or adjust the
connection
No
No
Is the CN71 normal?
Measure the resistance(Pin to Pin Full Check)
Normal : infinite
Abnormal : shorted
Is the CN71
disconnected or loose
Connection?
1. Comm harness and connector
Replace The PCB

LG LSE4617ST Specifications

General

Style	single oven, slide-in
Color	stainless steel
Total Capacity	6.3 cubic feet
Options	bake, speed broil, broil, convection bake, convection roast, speed roast, warm, proof, delay bake option, delay clean option, time bake, timer
Cooking Programs	bake, broil, convection, proof, roast
Convection	single-fan with heating element
Induction	yes
Number of Burners / Elements	5
Number of Oven Racks	3
Number of Oven Rack Positions	7
Control Type	knob, touchpad
Interior Light	yes
Child Lock	yes
Smart Home	true, amazon alexa, google assistant
Wi-Fi	wi-fi
Fuel	electric
Voltage	208 volts
Current	40 amperes

Weight and Dimensions

Depth	28 15/16 inches
Height	37 7/8 inches
Width	30 inches
Net Weight	185 pounds
