61
APPENDIX
PRODUCT SPECIFICATIONS
■ The specifications shown above may be changed without prior notice for quality improvement.
<M2280A / M2280AF>
LCD Panel
Screen Type
546.86 mm Wide (21.53 inch) TFT (Thin Film Transistor)
LCD (Liquid Crystal Display) Panel
Visible diagonal size: 546.86 mm
Pixel Pitch 0.248 mm (H) x 0.248 mm (V)
Video Signal
Max. Resolution 1920 x 1080 @ 60 Hz
Recommended Resolution 1920 x 1080 @ 60 Hz
Horizontal Frequency 30 kHz to 69 kHz
Vertical Frequency 56 Hz to 61 Hz
Synchronization Type Separate Sync
Input Connector CVBS, TV, D-Sub Analog, HDMI, PC Audio In, component
Power
Rated Voltage 19 V 2.2 A
Power Consumption
On Mode : 30W (Typ.)
Sleep Mode: 1 W (RGB)
Off Mode: 0.5 W
AC/DC Adapter Manufacturer: LITE-ON, Model PA-1650-68
Tilt Tilt Range
-5° to 10°
Dimensions (Width x Height x Depth)
Weight
M2280A
509.6 mm x 396.2 mm x 193.8 mm (20.06 inch x 15.59 inch x 7.62 inch)
3.6 kg (7.93 lb)
M2280AF
509.6 mm x 407.3 mm x 193.9 mm (20.06 inch x 16.03 inch x 7.63 inch)
3.8 kg (8.37 lb)
Environmental
conditions
Operating Temperature
Operating Humidity
10 °C to 35 °C
20 % to 80 %
-10 °C to 60 °C
5 % to 90 %
Storage Temperature
Storage Humidity
