LG M2280DF User Manual

144
APPENDIX
APPENDIX
M2380D / M2380DF/ M2380DB / M2380DN
LCD Panel
Screen Type
584.2 mm Wide (23 inch) TFT (Thin Film Transistor)
LCD (Liquid Crystal Display) Panel
Visible diagonal size: 584.2 mm
Pixel Pitch
0.265 mm (H) x 0.265 mm (V)
Video Signal
Max. Resolution
1920 x 1080 @ 60 Hz
Recommended Resolution
1920 x 1080 @ 60 Hz
Horizontal Frequency
30 kHz to 83 kHz
Vertical Frequency
56 Hz to 75 Hz
Synchronization Type
Separate Sync, Digital
Input Connector
TV, D-Sub Analog, SCART, PC Audio In, component, HDMI*2, CVBS
Power
Rated Voltage
19 V 2.4 A
Power Consumption
On Mode 40 W (typ.)
Off Mode ≤ 1 W
AC/DC Adapter Manufacturer: LITE-ON, Model PA-1650-68
Tilt Tilt Range
-5° to 10°
Dimensions (Width x Height x Depth)
Weight
M2380D
547 mm x 415.7 mm x 193.8 mm (21.53 inch x 16.37 inch x 7.63 inch)
4.2 kg ( 9.26 lb)
M2380DF
547 mm x 427.9 mm x 193.9 mm (21.53 inch x 16.85 inch x 7.6 inch)
4.4 kg ( 9.7 lb)
M2380DB
547 mm x 429.1 mm x 194.4 mm (21.53 inch x 16.89 inch x 7.65 inch)
4.2 kg ( 9.26 lb)
M2380DN
547 mm x 349.6 mm x 57.8 mm (21.53 inch x 13.76 inch x 2.27 inch)
3.4 kg ( 7.5 lb)
Environmental
conditions
Operating Temperature
Operating Humidity
10 °C to 35 °C
20 % to 80 %
-10 °C to 60 °C
5 % to 90 %
Storage Temperature
Storage Humidity
■ The specifications shown above may be changed without prior notice for quality improvement.
