LG M2362D User Manual

9988
TO USE A USB DEVICE
Music Selection and PopUp Menu
USB Device
Page 2/3
No Marked
Music List
Up Folder
Free Space 150MB
1:340, 120KB
Up Folder
4395KB
1Kbps
Play
Play with Photo
Mark All
Delete
Close
G
PPllaayy
(During stop) : Play the selected music titles.
Once a music finishes playing, the next selected one
will be played. When there are no selected music
titles to play, the next one in the current folder will be
played. If you go to a different folder and press the
OO KK
button, the current music in playback will stop.
G
PPllaayy MMaarrkkeedd
: Play the selected music titles. Once
a music finishes playing, the next selected one will be
played automatically.
G
SSttoopp PPllaayy
(During playback) : Stop the playing
music titles.
G
PPllaayy wwiitthh PPhhoottoo
: Start playing the selected music
titles and then move to the Photo List.
G
MMaarrkk AAllll
: Mark all music titles in the folder.
G
UUnnmmaarrkk AAllll
: Deselect all marked music titles.
G
DDeelleettee
: Delete the selected music titles.
G
CClloossee
: Close the pop-up menu.
• Use the
PP
button to navigation in the
music page.
• Use
MMAARRKK
button to mark or unmark a music.
When one or more music files are marked, the
marked music title will be played in sequence.
For example, if you want to listen to only one
music repeatedly, just mark the music only and
play it. If no music is marked, all the music in the
folder will be played in sequence.
As shown , up to 6 music titles are listed per page.
USB Device
Page 2/3
No Marked
Music List
Up Folder
Free Space 150MB
1:340, 120KB
Up Folder
Music
Music
Select the target folder or drive.
Select the desired music title
Show the PopUp menu.
Select the desired PopUp menu.
2
3
1
4
OK
OK
OK
Title
Duration
Title
Duration
Navigation Option Page Change Mark Exit
P
MARK RETURN
Navigation Option Page Change Mark Exit
P
MARK RETURN
•
Press the RETURN button to close the menu window.

LG M2362D Specifications

LCD Panel Specification

screen size	23” Class (23.0” diagonal)
resolution	1920 x 1080p
brightness	300 cd/m2 (Typical)
dynamic contrast ratio	50, 000:1
response time	5ms (Typical)
viewing angle	170º/160º
color supported	16.7M
aspect ratio	16:9
panel surface	Anti-Glare, 3H

Audio/Video Input/Outputs

hdmi	2
15 pin D-Sub	1
dvi-d	1
composite	1
scart	2
pc audio in	1
headphone out	1

Power

voltage, hz	100V ~ 240V, 56/75Hz
on mode power consumption	55W (Max)
standby mode power consumption	1W (Max)
off mode power consumption	0.5W (Max)

Dimensions & Weight

monitor with stand dimensions	21.7” x 16.5” x 8.7”
monitor without stand dimensions	21.7” x 14.9” x 2.6”
shipping dimensions	24.7” x 18.9” x 5.5”
monitor with stand weight	10.4 lbs
monitor without stand weight	9.7 lbs
shipping weight	13.7 lbs
