7700
SOUND CONTROL
SELECTING DIGITAL AUDIO OUT
This function allows you to select your preferred Digital Audio Output.
The TV can only output DOLBY Digital if a channel is broadcast with Dolby Digital audio.
When Dolby digital is available, selecting Auto in the Digital Audio Out menu will set SPDIF(Sony Philips Digital
InterFace) output to Dolby Digital.
If Auto is selected in the digital audio out menu when dolby digital is not available, SPDIF output will be PCM(Pulse-
code modulation).
Even if both Auto and Audio language have been set in a channel which broadcast Dolby Digital Audio, only Dolby
Digital will be played.
If the sample rate converter on this chip does not support 44.1 to 48kHz, this content should always produce
stereo PCM at digital output.
Select
AAUUDDIIOO
.
Select
DDiiggiittaall AAuuddiioo OOuutt
.
3
Select
AAuuttoo
or
PP CCMM
.
1
2
MENU
OK
OK
Press the MENU or EXIT button to close the menu window.
Press the RETURN button to move to the previous menu screen.
Manufactured under license from
Dolby Laboratories. “Dolby “and
the double-D symbol are trade-
marks of Dolby Laboratories.
There is a possibility that when HDMI mode,
some DVD players do not make SPDIF sound.
At that time, set the output of the digital audio
of the DVD player to PCM.
Balance 0
Sound Mode : Standard
• SRS TruSurround HD : Off
• Treble 50
• Bass 50
• Reset
Digital Audio Out : PCM
TV Speaker : On
AUDIO
Move
OK
E
DDiiggiittaall AAuuddiioo OOuutt :: PPCCMM
LR
Balance 0
Sound Mode : Standard
• SRS TruSurround HD : Off
• Treble 50
• Bass 50
• Reset
Digital Audio Out : PCM
TV Speaker : On
AUDIO
Move
OK
E
DDiiggiittaall AAuuddiioo OOuutt :: PPCCMM
LR
Auto
PCM
PCM
D
D

Table of Contents

Other manuals for LG M2362D

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the LG M2362D and is the answer not in the manual?

LG M2362D Specifications

LCD Panel Specification IconLCD Panel Specification
screen size23” Class (23.0” diagonal)
resolution1920 x 1080p
brightness300 cd/m2 (Typical)
dynamic contrast ratio50, 000:1
response time5ms (Typical)
viewing angle170º/160º
color supported16.7M
aspect ratio16:9
panel surfaceAnti-Glare, 3H
Audio/Video Input/Outputs IconAudio/Video Input/Outputs
hdmi2
15 pin D-Sub1
dvi-d1
composite1
scart2
pc audio in1
headphone out1
Power IconPower
voltage, hz100V ~ 240V, 56/75Hz
on mode power consumption55W (Max)
standby mode power consumption1W (Max)
off mode power consumption0.5W (Max)
Dimensions & Weight IconDimensions & Weight
monitor with stand dimensions21.7” x 16.5” x 8.7”
monitor without stand dimensions21.7” x 14.9” x 2.6”
shipping dimensions24.7” x 18.9” x 5.5”
monitor with stand weight10.4 lbs
monitor without stand weight9.7 lbs
shipping weight13.7 lbs
