APPENDIX
PRODUCT SPECIFICATIONS
■
The specifications shown above may be changed without prior notice for quality improvement.
Power
AC 100-240V ~ 50/60 Hz 1.2A
On Mode : 63W (typ.)
Sleep Mode 1W
Off Mode 0.5W
LCD Panel
Screen Type
Pixel Pitch
27 inches Wide (686 mm) TFT (Thin Film Transistor)
LCD (Liquid Crystal Display) Panel
Visible diagonal size: 686 mm
0.3114(H) x 0.3114(V) mm
Max. Resolution
Recommended Resolution
Horizontal Frequency
Vertical Frequency
Synchronization Type
Video Signal
1920 X 1080 @60 Hz
1920 X 1080 @60 Hz
30 - 83 kHz
56 - 75 Hz
Separate Sync, Digital
Input Connector
TV, D-Sub Analog, SCART*2, PC Audio In, component, DVI-D, HDMI*2, CVBS
Rated Voltage
Power Consumption
Tilt
Tilt Range
Swivel Range
Swivel
Dimensions
(Width x Height x Depth)
Weight
649.1 x 485 x 210 mm (25.56 x 19.09 x 8.27 inches)
7.2 kg / 15.87 lbs
Operating Temperature
Operating Humidity
Storage Temperature
Storage Humidity
Environmental
conditions
10 ~ 35°C
20 ~ 80%
-10 ~ 60°C
5 ~ 90%
-5 ~ 15
°
358°
<<MM22776622DD>>

LG M2362D Specifications

LCD Panel Specification

screen size	23” Class (23.0” diagonal)
resolution	1920 x 1080p
brightness	300 cd/m2 (Typical)
dynamic contrast ratio	50, 000:1
response time	5ms (Typical)
viewing angle	170º/160º
color supported	16.7M
aspect ratio	16:9
panel surface	Anti-Glare, 3H

Audio/Video Input/Outputs

hdmi	2
15 pin D-Sub	1
dvi-d	1
composite	1
scart	2
pc audio in	1
headphone out	1

Power

voltage, hz	100V ~ 240V, 56/75Hz
on mode power consumption	55W (Max)
standby mode power consumption	1W (Max)
off mode power consumption	0.5W (Max)

Dimensions & Weight

monitor with stand dimensions	21.7” x 16.5” x 8.7”
monitor without stand dimensions	21.7” x 14.9” x 2.6”
shipping dimensions	24.7” x 18.9” x 5.5”
monitor with stand weight	10.4 lbs
monitor without stand weight	9.7 lbs
shipping weight	13.7 lbs
