LG M2362D User Manual

111199
APPENDIX
0088.. CCoolloouurr ((CCoommmmaanndd:: kk ii))
G To adjust the screen colour.
You can also adjust colour in the PICTURE menu.
Transmission
Data Min : 00 ~ Max : 64
*
Refer to ‘Real data mapping’. See page 121.
[k][i][ ][Set ID][ ][Data][Cr]
Ack
[i][ ][Set ID][ ][OK/NG][Data][x]
0044.. VVoolluummee MMuuttee ((CCoommmmaanndd:: kk ee))
G To control volume mute on/off.
You can also adjust mute using the MUTE button on
remote control.
Transmission
Data 00 : Volume mute on (Volume off)
01 : Volume mute off (Volume on)
[k][e][ ][Set ID][ ][Data][Cr]
Ack
[e][ ][Set ID][ ][OK/NG][Data][x]
0022.. AAssppeecctt RRaattiioo ((CCoommmmaanndd:: kk cc)) ((MMaaiinn PPiiccttuurree SSiizzee))
G To adjust the screen format. (Main picture format)
You can also adjust the screen format using the
AAssppeecctt RRaattiioo
in the PICTURE menu.
(1) ATV, AV1,2,3 Input mode
- 16:9 / Original / 4:3 / 14:9 / Cinema Zoom /
Zoom / Full Wide
(2) DTV
- 16:9 / Just Scan / Original / 4:3 / 14:9 / Cinema
Zoom / Zoom
(3) RGB, DVI, HDMI Input (HDMI-PC) mode
- 4:3 / 16:9
(4) Component, HDMI input (not HDMI-PC) mode
- 16:9 / 4:3 / 14:9 / Cinema Zoom / Zoom
(Just Scan : Only 720p over)
Transmission
Data 01 : Normal screen (4:3)
02 : Wide screen (16:9)
04 : Zoom
06 : Original
07 : 14:9
09 : Just Scan
0B : Full Wide
10 ~1F : Cinema Zom 1~16
[k][c][ ][Set ID][ ][Data][Cr]
Ack
[c][ ][Set ID][ ][OK/NG][Data][x]
0055.. VVoolluummee CCoonnttrrooll ((CCoommmmaanndd:: kk ff))
G To adjust volume.
You can also adjust volume with the VOLUME buttons
on remote control.
Transmission
Data Min : 00 ~ Max : 64
*
Refer to ‘Real data mapping’. See page 121.
[k][f][ ][Set ID][ ][Data][Cr]
Ack
[f][ ][Set ID][ ][OK/NG][Data][x]
0066.. CCoonnttrraasstt ((CCoommmmaanndd:: kk gg))
G To adjust screen contrast.
You can also adjust contrast in the PICTURE menu.
Transmission
Data Min : 00 ~ Max : 64
*
Refer to ‘Real data mapping’. See page 121.
[k][g][ ][Set ID][ ][Data][Cr]
Ack
[g][ ][Set ID][ ][OK/NG][Data][x]
0077.. BBrriigghhttnneessss ((CCoommmmaanndd:: kk hh))
G To adjust screen brightness.
You can also adjust brightness in the PICTURE menu.
Transmission
Data Min : 00 ~ Max : 64
*
Refer to ‘Real data mapping’. See page 121.
[k][h][ ][Set ID][ ][Data][Cr]
Ack
[h][ ][Set ID][ ][OK/NG][Data][x]
0011.. PPoowweerr ((CCoommmmaanndd:: kk aa))
G To control Power On/Off of the TV.
Transmission
Data 00 : Power Off 01 : Power On
[k][a][ ][Set ID][ ][Data][Cr]
Ack
[a][ ][Set ID][ ][OK/NG][Data][x]
0033.. SSccrreeeenn MMuuttee ((CCoommmmaanndd:: kk dd))
G To select screen mute on/off.
Transmission
Data 00 : Screen mute off (Picture on)
01 : Screen mute on (Picture off)
[k][d][ ][Set ID][ ][Data][Cr]
Ack
[d][ ][Set ID][ ][OK/NG][Data][x]

LG M2362D Specifications

LCD Panel Specification

screen size	23” Class (23.0” diagonal)
resolution	1920 x 1080p
brightness	300 cd/m2 (Typical)
dynamic contrast ratio	50, 000:1
response time	5ms (Typical)
viewing angle	170º/160º
color supported	16.7M
aspect ratio	16:9
panel surface	Anti-Glare, 3H

Audio/Video Input/Outputs

hdmi	2
15 pin D-Sub	1
dvi-d	1
composite	1
scart	2
pc audio in	1
headphone out	1

Power

voltage, hz	100V ~ 240V, 56/75Hz
on mode power consumption	55W (Max)
standby mode power consumption	1W (Max)
off mode power consumption	0.5W (Max)

Dimensions & Weight

monitor with stand dimensions	21.7” x 16.5” x 8.7”
monitor without stand dimensions	21.7” x 14.9” x 2.6”
shipping dimensions	24.7” x 18.9” x 5.5”
monitor with stand weight	10.4 lbs
monitor without stand weight	9.7 lbs
shipping weight	13.7 lbs
