No. Item Content Unit Remark
1. Product Width(W) Length(D) Height(H) mm
Dimension Before Packing 649.1 210 485 mm
After Packing 729 539 170 mm
2. Product Only SET 7.2 Kg
Weight With BOX 9.8 Kg
3. Container Individual or 20ft 40ft
Loading Palletizing Indi. Wooden Indi. Wooden
Quantity 416 360 858 792
4. Stand
Type Detachable ( Base detachable)
Assy
Size(W x D x H) 330.0 x 210.0 x 51.8
Tilt Degree -5~15 degree
Tilt force 1.0~3.5kgf
Swivel Degree 358 degree
Swivel Force 0.5 ~ 2.kgf
5. Appearance General Refer to Standard of LG(55)G1-1020
*Appearance Gap spec
Front: 0.5 mm
Back & Bottom : 1.0 m
8.Mechanical Specification
