LG M2762DP-EML User Manual

- 8 -
Copyright ©2010 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
* Optical Test Condition (Revision 3)
- Surrounding Brightness Level : dark
- Surrounding Temperature : 25±5°
- warm-up Time : 30 Min
- Contrast, Brightness : Outgoing condition
-. *Incase of Vivid Mode, high level saturation may be occurred. Check gray linearity at standard mode.
6. LCD Module Optical characteristics
Panel Optical Char.
* Active area
1. Active area of LCD PANEL is in bezel of cabinet.
2. Interval between active area and bezel
|A-B| ≤ 1.0 mm , |C-D| ≤ 1.0 mm
A: Interval between left of active area and bezel
B: Interval between right of active area and bezel
C: Interval between top of active area and bezel
D: Interval between bottom of active area and bezel
C
B
D
A
Active Area
Bezel
