Page #47 background imageLoading...
Page #47 background image
3-46
Copyright © 2008 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
PWM5_M 61 O Negative PWM output of channel 5.
PWM6_P 68 O Positive PWM output of channel 6.
PWM6_M 67 O Negative PWM output of channel
6.
PWM7_P 71 O Positive PWM output of channel 7.
PWM7_M 70 O Negative PWM output of channel
7.
PWM8_P 75 O Positive PWM output of channel 8.
PWM8_M 74 O Negative PWM output of channel
8.
PWM_HP_L_P 46 O Positive PWM output of headphone left
channel.
PWM_HP_L_M 45 O Negative PWM output of headphone left
channel.
PWM_HP_R_P 41 O Positive PWM output of headphone right channel.
PWM_HP_R_M 40 O Negative PWM output of headphone right channel.
PWM_SWL_P 37 O Positive PWM output of subwoofer
line output.
PWM_SWL_M 36 O Negative PWM output of subwoof
er line output.
System Control Interface
SPI/I2C 84 I Host interface mode (SPI or I2C) selector.
Assert ëHIGHí for SPI mode. De-assert ëLOWí for I2C mode.
Internal pull-down resistor.
SO/SDA 78 I/O SO for SPI mode or SDA for I2C
mode.
SCK/SCL 79 I SCK for SPI mode or SCL for I2C mode.
Schmitt-Trigger i
nput.
SI/I2C_AD0 82 I SI for SPI mode or Slave Address 0 for I2C mode.
Schmitt-Trigger input.
Internal pull-down resistor.
/CS/I2C_AD2 83 I Chip selector (CS) for SPI mode or Slave Address 2 for I2C
mode.
Schmitt-Trigger input.
Internal pull-down resistor.
Special Control Interface
EXT_MUTE 27 I External mute control input. Active High.
Assert ëHIGHí to mute audio output.
Internal pull-down resistor.
OVERLOAD 76 I Power stage overload indication input.
Polarity is programmable. Schmitt-Trigger input.
When OVERLOAD is asserted, all PWM audio outputs go to
ìLOWî. That shutdown process is programmable.
Internal pull-down resistor.
EPD_ENA 77 O External amplifier power device enable output.
Active High.
Test Mode
TEST_MODE1 97 I Test mode selection pin 1.
In normal operation, it should be ìLOWî or not connected.
Internal pull-down resistor.
TEST_MODE2 98 I Test mode selection pin 2.
In normal operation, it should be ìLOWî or not connected.
Internal pull-down resistor.
SCAN_ENA 99 I Scan enable. Active High.
In normal operation, it should be ìLOWî or not connected.
Internal pull-down resistor.
TEST_MODE3 100 I Test mode selection pin 3.
In normal operation, it should be ìLOWî or not connected.
Internal pull-down resistor.
All inputs and bi-directional inputs are 5 Volt tolerant. The corresponding pins can be connected to the buses that can
swing between 0V and 5V. The output-only pins are not 5V tolerant and the buses they are connected to can swing only
between 0V and 3.3V.
