SPECIFICATIONS
• GENERAL
Power supply 110~240 V, 50/60 Hz
Power consumption Refer to main label
Dimensions (W x H x D) 273 x 333 x 339 mm without foot
Net Weight (Approx.) 5.7 kg
Operating temperature 41 °F to 95 °F (5 °C to 35 °C)
Operating humidity 5 % to 90 %
Bus Power supply (USB) DC 5V 500mA
• INPUTS/ OUTPUTS
VIDEO OUT 1.0 V (p-p), 75 Ω, sync negative, RCA jack x 1
COMPONENT VIDEO OUT (Y) 1.0 V (p-p), 75 Ω, sync negative, RCA jack x 1,
(Pb)/(Pr) 0.7 V (p-p), 75 Ω, RCA jack x 2
ANALOG AUDIO IN 0.6 Vrms, 47 kΩ, RCA jack (L, R) x 1
PORT. IN 0.5 Vrms (3.5 mm stereo jack)
• TUNER
FM Tuning Range 87.5 to 108.0 MHz or 87.50 to 108.00 MHz
AM Tuning Range 522 to 1 620 kHz, 520 to 1 710 kHz or 522 to 1 710 kHz
• AMPLIFIER
Stereo mode 150 W + 150 W (4 Ω at 1 kHz)
Surround mode
Front 150 W + 150 W (4 Ω at 1 kHz)
Center 70 W (6 Ω at 1 kHz)
Surround 70 W + 70 W (6 Ω at 1 kHz)
Subwoofer 200 W (3 Ω at 60 Hz)
1-7
