LG MDT352 - Front Panel and Rear Panel Overview

4
Front Panel/ Rear Panel
1. DISPLAY WINDOW
2. • (
/
[
)POWER button
• CLOCK button
• TIMER button
• DUBBING (DUBB.)/ CD SYNCHRO RECORDING
(CD SYNC.)/ (ST./MO.) button
3. MULTI JOG
• MANUAL TUNING
• CD SKIP
• CLOCK ADJUST
4. HEADPHONE Jack (PHONES): 3.5 mm
5. USB connector
6. • FUNCTION SELECT buttons
(TUNER,TAPE, DVD/CD,AUX)
• EQ. button
• XTS Pro button
• USB button
• XDSS plus button
• Volume control knob
7. Z PUSH EJECT position (TAPE 1)
8. Z PUSH EJECT position (TAPE 2)
9. • RECORD/RECORD PAUSE (zREC/[]) button
• TUN.(-/+) buttons -AUTO TUNING/
REWIND/ FAST FORWARD (
FF
/
GG
) -TAPE/
SCAN (
FF
/
GG
) buttons -CD
• PRESET (-/+) buttons/ TAPE REVERSE PLAY
(
bb
) button (OPTIONAL) /TAPE FORWARD PLAY
(
BB
) button
• STOP (xSTOP) button
3
4
5
6
7
8
9
10
11
12
13
1
18
15
14
17
10. MIC JACKS (MIC1, MIC2): 6.3 mm : OPTIONAL
11. MIC VOLUME (MIC VOL.) knob
12. Remote control sensor
13. • OPEN/CLOSE (ZOP/CL) button
• DISC SKIP (D.SKIP) button
• PLAY MODE, DEMO button
• SET/CD
[]
, RDS (OPTIONAL) button
14. DISC DOOR
15. •
COMPONENT VIDEO OUT (PROGRESSIVE SCAN)
(Y PB PR) Connector
• VIDEO OUT Connector
16. • FM/AM ANTENNA Connector
• AUXILIARY INPUT (AUX IN) connector
17. POWER CORD
18. SPEAKER Connectors (MDT352 Model)
19. SPEAKER Connectors (MDD262 Model)
16
MDD262 Model
MDT352 Model
19
2
