LG Monitor

4-3. Tiling Displays : How to Join Sets - Installing Set 2
Join Set 2 to Set 1 using the guide brackets on the top side of Set 1 and mount the two
sets to the wall mount plate or the wall.
Remove the guide brackets after mounting the sets.
The sets joined with the guide brackets
<Rear view of the set with the wall mount plate>
The sets after removing the guide brackets
