LG MULTI V ARNU Series User Manual

Dimensions
- 13 -
Copyright ©2010 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
76, Seongsan-dong, Changwon City, Gyeongnam,
641-713, Korea
CHASSIS CODE: TU
Ceiling Cassette 1-way
ARNU07GTU*2 ARNU09GTU*2 ARNU12GTU*2
Name
1 Liquid pipe connection
Unit size(7k, 9k, 12k):ø6.35
2 Gas pipe connection
Unit size(7k, 9k, 12k):ø12.7
3 Air suction grill 4 Air discharge grill
Number Descripition
Note
1. Unit should be installed in compliance with the installation manual in the product box. 2. Unit shall be grounded in accordance with the local regulations or applicable national codes.
(unit : mm)
(Panel Name: PT-UUD)
453
46.5
57.4
34
117
96.5
168.3
106.8
206.3
275.8
109.5
861
1012
88
1100
109.5
453
320.5
27
500
354.3
