LG Multi V ARUB Series - Page 39

Installation Manual 39
ENGLISH
5m(16ft)
15m(49ft)
1) under 40m
Keep the sum of indoor capacity under 56.4kW(192 kBtu/h).
Indoor
Unit
Indoor
Unit
Indoor
Unit
Indoor
Unit
Indoor
Unit
Indoor
Unit
Indoor
Unit
Indoor
Unit
Indoor
Unit
Indoor
Unit
Indoor
Unit
Indoor
Unit
1) under 40m
Y branch
Keep the sum of indoor capacity under 56.4kW(192 kBtu/h).
1) Keep the 40m distance from the first branch to the farthest indoor.
Refrigerant piping system
