Exploded View
- 10 -
Copyright ©2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
7.1.2 PRHR031/PRHR031A
135500B
249951
13 55 00A
W4810A
W54100B
137213B
55211FB
55211FA
W4810B
55 21 1G
W54100A
13 04 01
137213A
352118
552204A
552204B
149900
552204B
55 22 00
56 14 10B
56 14 10A
56 14 10C
56 14 10G56 14 10F56 14 10E
56 14 10I
249951
W6640B
W6640A
W4004
26 17 04
268711
Part L/No. Sensor Location Remark
Thermistor 1
263230
SC out heatproof PVC : blue
Thermistor 2 SC in heatproof PVC : white
Thermistor 3 Liquid heatproof PVC : black
