LG Multi V S - Checking the Setting of Outdoor Units

60
ELECTRICAL WIRING
ENGLISH
Checking the setting of outdoor units
Checking according to DIP switch setting
- You can check the setting values of the Master outdoor unit from the 7 segment LED.
The DIP switch setting should be changed when the power is OFF.
Checking the initial display
The number is sequentially appeared at the 7 segment in 5 seconds after applying the power.
This number represents the setting condition. (For example, represents R410A 10 HP)
• Initial display order • Example) ARUN100LSS0
Order No Note
①
4~14 Model capacity
②
1 Cooling only
2 Heat pump
③
38 380 V
46 460 V
22 220 V
④
1 Standard
5 Cold temperature area
6 Tropical
① ② ③ ④
10 2 38 1
