OUTDOOR UNITS INFORMATION
9
ENGLISH
Power Supply : 3 Ø, 380-415 V3N, 50 Hz / 3 Ø, 380 V3N, 60 Hz
Power Supply : 1 Ø, 220-240 V~, 50 Hz / 1 Ø, 220 V, 60 Hz
CAUTION
!
• Ratio of the connectable Indoor Units to the Outdoor: Within 50 ~ 160 %
• Ratio of running Indoor Units to the Outdoor: Within 10 ~ 100 %
• A combination operation over 100 % cause to reduce each indoor unit capacity.
OUTDOOR UNITS INFORMATION
Series 0 Series
Chasis U3
System(HP) 4 5 6 8
Refrigerant Precharged
Amount
kg 3 3 3 3.5
lbs 6.6 6.6 6.6 7.7
Piping
Connections
Liquid Pipes mm(inch) Ø 9.52(3/8) Ø 9.52(3/8) Ø 9.52(3/8) Ø 9.52(3/8)
Gas Pipes mm(inch) Ø 15.88(5/8) Ø 15.88(5/8) Ø 15.88(5/8) Ø 15.88(5/8)
Series 0 Series
Chasis U7
System(HP) 10 12 14
Refrigerant Precharged
Amount
kg 4.5 6 6
lbs 9.9 13.2 13.2
Piping
Connections
Liquid Pipes mm(inch) Ø 9.52(3/8) Ø 12.7(1/2) Ø 12.7(1/2)
Gas Pipes mm(inch) Ø 22.2(7/8) Ø 28.58(11/8) Ø 28.58(11/8)
Series 0 Series
Chasis U4 U3
System(HP) 4 5 6
Refrigerant Precharged
Amount
kg 1.8 3 3
lbs 4 6.6 6.6
Piping
Connections
Liquid Pipes mm(inch) Ø 9.52(3/8) Ø 9.52(3/8) Ø 9.52(3/8)
Gas Pipes mm(inch) Ø 15.88(5/8) Ø 15.88(5/8) Ø 19.05(3/4)
Series 5 Series
Chasis U4
System(HP) 5 6
Refrigerant Precharged
Amount
kg 2.4 2.4
lbs 5.3 5.3
Piping
Connections
Liquid Pipes mm(inch) Ø 9.52(3/8) Ø 9.52(3/8)
Gas Pipes mm(inch) Ø 15.88(5/8) Ø 19.05(3/4)
