LG Multi V ZRUM080LTE6 User Manual

ZRUM140LTE6
Category
Unit Specification
Major Minor
Classification
Chassis - UXB
Combination Unit (1) - ZRUM140LTE6
Combination Unit (2) - -
Combination Unit (3) - -
Combination Unit (4) - -
Power Supply
Case 1 V, Phase, Hz 380-400-415, 3, 50
Limit Range of Voltage(Case 1) V 342 ~ 456
Case 2 V, Phase, Hz 380, 3, 60
Limit Range of Voltage(Case 2) V 342 ~ 418
Running Current by Voltage (Cooling,Rated) A 19.41 - 18.44 - 17.77
Running Current by Voltage (Heating,Rated) A 13.77 - 13.08 - 12.61
Cooling Capacity Rated
kW 39.2
Btu/h 133,800
Heating Capacity
Rated
kW 39.2
Btu/h 133,800
Max
kW 44.1
Btu/h 150,500
Power Input(Cooling) Rated kW 11.88
Power Input(Heating) Rated kW 8.43
Efficiency
EER(Rated) W/W 3.30
COP(Rated) W/W 4.65
SEER Wh/Wh 8.55
SCOP Wh/Wh 5.17
Power Factor(Cooling/Heating) Rated - 0.93 / 0.93
Outdoor Fan
Type - Propeller fan
Air Flow Rate(High) m³/min 320
Max. External Static Pressure Pa 80
Discharge direction(Side / Top) - Top
Outdoor Fan Motor
Type - BLDC
Drive - Direct
Output W x No. 900 x 2
Compressor
Type - Hermetically Sealed Scroll
Piston Displacement cm³/rev 62.1
Number of Revolution rev./min 3,600
Motor Output W x No. 5,300 x 1
Starting Method - Inverter
Oil Type - FW68L(PVE)
Heat Exchanger
Type - Fin & Tube
No. - 1
Fin Type - Wide Louver Plus
Dimensions
Net(W x H x D) mm 1,240 x 1,745 x 760
Shipping(W x H x D) mm 1,282 x 1,919 x 802
Weight
Net kg 255
Shipping kg 265
Exterior
Color - Morning Gray / Dawn Gray
RAL (Classic) - RAL 7038 / RAL 7037
Protection Device
High Pressure Prevention - High pressure sensor / High pressure switch
Frost Prevention - O (Logical)
Discharge Tempreature Control - O (Logical)
Compressor/Fan Protection - Over-heat protection / Fan driver overload protector
Inverter Protection - Over-heat protection / Over-current protection
Multi V i
1. Specifications
Product Data
1-7
