6.1 General Instruction
■ Wiring of Main Power Supply
• Bear in mind ambient conditions (ambient temperature,direct sunlight, rain liquid,etc.) when proceeding with the wiring and
connections
• The wire size is the minimum value for metal conduit wiring. The power cord size should be 1 rank thicker taking into
account the line voltage drops. Make sure the power-supply voltage does not drop more than 10%.
• Specific wiring requirements should adhere to the wiring regulations of the region.
• Power supply cords of parts of appliances for outdoor use should not be lighter than polychloroprene sheathed flexible cord
(design 60245 IEC57).
• Don't install an individual switch or electrical outlet to disconnect each of indoor unit separately from the power supply.
< ! > WARNING
• Make sure to use specified wires for connections so that no external force is imparted to terminal connections.
If connections are not fixed firmly, it may cause heating or fire.
• Make sure to use the appropriate type of overcurrent protection switch. Note that generated overcurrent may include some
amount of direct current.
• All Installation site must require attachment of an earth leakage breaker.
If no earth leakage breaker is installed, it may cause an electric shock.
• Do not use anything other than breaker and fuse with correct capacity. Using fuse and wire or copper wire with too large
capacity may cause a malfunction of unit or fire.
Installation of Outdoor Unit
6. Field Wiring
Installation
23
