1.1 Product
ZRUM080LTE6
Category
Unit Specification
Major Minor
Classification
Chassis - UXA
Combination Unit (1) - ZRUM080LTE6
Combination Unit (2) - -
Combination Unit (3) - -
Combination Unit (4) - -
Power Supply
Case 1 V, Phase, Hz 380-400-415, 3, 50
Limit Range of Voltage(Case 1) V 342 ~ 456
Case 2 V, Phase, Hz 380, 3, 60
Limit Range of Voltage(Case 2) V 342 ~ 418
Running Current by Voltage (Cooling,Rated) A 9.97 - 9.47 - 9.13
Running Current by Voltage (Heating,Rated) A 8.43 - 8.01 - 7.72
Cooling Capacity Rated
kW 22.4
Btu/h 76,400
Heating Capacity
Rated
kW 22.4
Btu/h 76,400
Max
kW 25.2
Btu/h 86,000
Power Input(Cooling) Rated kW 6.10
Power Input(Heating) Rated kW 5.16
Efficiency
EER(Rated) W/W 3.67
COP(Rated) W/W 4.34
SEER Wh/Wh 8.28
SCOP Wh/Wh 4.45
Power Factor(Cooling/Heating) Rated - 0.93 / 0.93
Outdoor Fan
Type - Propeller fan
Air Flow Rate(High) m³/min 220
Max. External Static Pressure Pa 80
Discharge direction(Side / Top) - Top
Outdoor Fan Motor
Type - BLDC
Drive - Direct
Output W x No. 1,200 x 1
Compressor
Type - Hermetically Sealed Scroll
Piston Displacement cm³/rev 62.1
Number of Revolution rev./min 3,600
Motor Output W x No. 5,300 × 1
Starting Method - Inverter
Oil Type - FW68L(PVE)
Heat Exchanger
Type - Fin & Tube
No. - 1
Fin Type - Wide Louver Plus
Dimensions
Net(W x H x D) mm 930 x 1,745 x 760
Shipping(W x H x D) mm 965 x 1,919 x 802
Weight
Net kg 215
Shipping kg 225
Exterior
Color - Morning Gray / Dawn Gray
RAL (Classic) - RAL 7038 / RAL 7037
Protection Device
High Pressure Prevention - High pressure sensor / High pressure switch
Frost Prevention - O (Logical)
Discharge Tempreature Control - O (Logical)
Multi V i
1. Specifications
Product Data
1-1
