9.4 Simultaneous Operation (Heating)
ZRUM080LTE6, ZRUM100LTE6, ZRUM120LTE6, ZRUM140LTE6, ZRUM160LTE6, ZRUM180LTE6,
ZRUM200LTE6, ZRUM220LTE6, ZRUM240LTE6, ZRUM260LTE6, ZRUM280LTE6
10°C
15°C
10°C
5°C
0°C
-5°C
-10°C
15°C 20°C 25°C 27°C 30°
C
Outdoor Temperature(°C WB)
Range for continuous operation
Range for pull down operation
16°C
Indoor Temperature(°C DB)
20°C
Note
■ These figures assume the following operating conditions
: Equivalent piping length is standard condition, and level differenc is 0m.
■ Range of pull down operation: If the relative humidity is too high, cooling capacity can be decreased by the sensible heat reduction.
■ Warming up operation means that the outdoor(outside) unit operates to reach the range of continuous operating, however it may not operate continuously
due to safety or protection logic.
Multi V i
9. Operation Limits
Product Data
9-4
