LG Multi V ZRUM080LTE6 User Manual

10.2 Power Levels
ZRUM080LTE6
Cool Heat Cool Heat
op1~op3, op10 78.0 78.0 100 100
op4~op6, op11 78.0 78.0 100 100
op7~op9, op12 77.0 77.0 85 85
63 125 250 500 1000 2000 4000 8000 Overall [dB(A)]
92.7 79.2 75.8 75.6 71.4 67.7 69.5 62.0 78.0
92.7 79.2 75.8 75.6 71.4 67.7 69.5 62.0 78.0
Octave Band [Hz]
Cooling [dB]
Heating [dB]
Night Low Noise Control
Dip Switch
PWL [dB(A)]
Capacity [%]
10
20
30
40
50
60
70
80
90
100
110
120
63 125 250 500 1000 2000 4000 8000
Sound Power Level (0dB = 10E-6μW/m
2
)
Octave Band Center Frequency (Hz)
NR-70
NR-65
NR-60
NR-55
NR-50
NR-45
NR-40
NR-35
NR-30
NR-75
NR-25
NR-20
NR-80
NR-85
NR-90
■ Cooling
▲ Heating
NR-95
NR-100
NR-105
NR-110
Sound level [ dB(A), @ Standard condition ]
Cooling / Heating 78.0 / 78.0
Note
■ Data is valid at diffuse field condition.
■ Data is valid at nominal operating condition.
■ Reference acoustic intensity 0dB = 10E-6μW/m2
■ Refer to the Model Specifications for nominal conditions. (Power source and Ambient temperature, etc)
■ Sound power level is measured on the rated condition in the semi-anechoic rooms by ISO 9614 standard.
■ Sound levels can be increased in accordance with installation and operating conditions.
(Operating conditions include some functional condition like Static pressure mode, air guide use, Room target temperature setting, etc and these functions are
different in accordance with each model.)
■ Sound level will vary depending on a range of factors such as the construction(acoustic absorption coefficient) of particular room in which the equipment in
installed.
■ Refer to manual for setting dip switch of additional function.
■ In Night Low Noise Control, Capacity is tested at standard condition and 100% combination ratio. And It will be vary depending on combination idu,
environment and so on.
Multi V i
10. Sound Levels
Product Data
10-12
