Combi.
Outdoor
Air Temp.
Indoor Air Temp. (°C, DB)
16.0 18.0 20.0 21.0 22.0 24.0
(°C,
DB)
(°C,
WB)
TC PI TC PI TC PI TC PI TC PI TC PI
50
-19.8 -20 42.50 16.83 40.10 15.90 37.60 15.05 36.40 14.24 35.20 13.49 32.80 12.75
-18.8 -19 42.50 16.48 40.10 15.57 37.60 14.74 36.40 13.95 35.20 13.21 32.80 12.50
-16.7 -17 42.50 15.74 40.10 14.86 37.60 14.08 36.40 13.32 35.20 12.64 32.80 11.95
-15 -15.9 42.50 15.21 40.10 14.36 37.60 13.61 36.40 12.88 35.20 12.23 32.80 11.55
-13.7 -15 42.50 14.70 40.10 13.86 37.60 13.15 36.40 12.44 35.20 11.82 32.80 11.16
-11.8 -13 42.50 14.03 40.10 13.23 37.60 12.56 36.40 11.89 35.20 11.31 32.80 10.67
-9.8 -11 42.50 13.33 40.10 12.58 37.60 11.94 36.40 11.31 35.20 10.76 32.80 10.16
-9.5 -10 42.50 13.23 40.10 12.47 37.60 11.85 36.40 11.22 35.20 10.69 32.80 10.08
-8.5 -9.1 42.50 12.88 40.10 12.13 37.60 11.55 36.40 10.94 35.20 10.42 32.80 9.82
-7 -7.6 42.50 12.37 40.10 11.64 37.60 11.09 36.40 10.50 35.20 10.02 32.80 9.44
-5 -5.6 42.50 11.69 40.10 11.02 37.60 10.50 36.40 9.94 35.20 9.50 32.80 8.94
-3 -3.7 42.50 11.03 40.10 10.38 37.60 9.89 36.40 9.38 35.20 8.97 32.80 8.45
0 -0.7 42.50 10.03 40.10 9.43 37.60 9.01 36.40 8.54 35.20 8.20 32.80 7.70
3 2.2 42.50 9.03 40.10 8.48 37.60 8.12 36.40 7.71 35.20 7.43 32.80 6.96
5 4.1 40.30 7.73 37.80 7.24 35.30 6.92 34.10 6.57 32.80 6.34 30.40 5.90
7 6 37.90 6.57 35.50 6.12 32.90 5.87 31.70 5.56 30.40 5.36 28.00 4.99
9 7.9 35.50 5.46 33.00 5.08 30.40 4.86 29.20 4.59 28.00 4.44 25.40 4.10
11 9.8 32.90 4.70 30.50 4.37 28.00 4.16 26.60 3.94 25.40 3.80 22.90 3.50
13 11.8 30.40 4.05 27.90 3.76 25.30 3.59 24.00 3.40 22.80 3.27 20.20 3.00
15 13.7 27.70 3.53 25.20 3.28 22.60 3.11 21.30 2.95 20.10 2.84 17.40 2.61
Note
■ TC: Total Capacity(kW), PI : Power Input(kW, Comp. + Outdoor fan motor)
■ Advanced SLC : Providing better comfort and energy saving considering cooling load with both outdoor and indoor side and using temperature and
humidity dual sensing control.
■ Capacity tables show the average value of conditions which may occur.
Multi V i
7. Capacity Tables
Product Data
7-189
