4.6 Selection of Reducer
Ø6.35(1/4)OD9.52(3/8)
Indoor Unit
Reducer
PRHR023
PRHR033
PRHR043
PRHR063
PRHR083
HR Unit
Reducer*
Model
Low Pressure Gas pipe High Pressure Gas pipe Liquid pipe
OD15.88(5/8) Ø 12.7(1/2)
Ø6.35(1/4)OD9.52(3/8)
OD19.05(3/4) Ø15.88(5/8)
OD12.7(1/2) Ø9.52(3/8)
Ø
12.7(1/2)
OD22.2(7/8) Ø19.05(3/4) Ø15.88(5/8)
OD15.88(5/8) Ø12.7(1/2)
OD12.7(1/2) Ø9.52(3/8)
OD15.88(5/8)
Ø12.7(1/2)
Ø9.52(3/8)
OD19.05(3/4) Ø15.88(5/8)
OD28.58(1-1/8) Ø22.2(7/8) Ø19.05(3/4)
OD22.2(7/8) Ø19.05(3/4) Ø15.88(5/8)
OD15.88(5/8) Ø12.7(1/2)
[Unit : mm(inch)]
※
* : For Heat Recovery System Only
Installation of Outdoor Unit
4. Refrigerant Piping System
Installation
15
