30
MultiSITE CRC 2 Controller
Due to our policy of continuous product innovation, some specifications may change without notification.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
ACCESSORIES INSTALLATION
Door/Window Sensor Installation
1. Remove the base cover screw and base cover. Pull out the battery isolation strip
and then replace the cover and screw.
2. Attach the window/door sensor to the window or door, observing the following:
Where possible, install the main (sensor) part base plate on the window/door
frame, and the sub (magnet) part on the window/door itself.
The sub part must be installed so that it is located on the sensing side of the
main part when the window/door is closed
The main part base plate has arrow indicators to help with alignment and posi-
tioning..
Recommended distance from main part to sub part when window/door is closed:
Wood: <11/16 inch
Plastic: <11/16 inch
Metal: <3/8 inch
For wood or plastic surfaces, use either the adhesive pads P or the mounting
screws. (If using screws, pre-drill a 1/32 in hole.)
For metal surfaces, use the adhesive pads only.
3. Attach the main part to the base plate (Figure 36) by inserting the hooks on the
base plate into the holes on the main part.
Figure 36: Door/Window Sensor Installation
Ø 1/32 in
