22
MultiSITE CRC 2 Controller
Due to our policy of continuous product innovation, some specifications may change without notification.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
ACCESSORIES INSTALLATION
Wall Mounted Motion Sensor
Follow this procedure to install the optional
wireless wall mounted motion sensor.
Consider the following location constraints before
installing a wall mounted sensor:
• Do not install on a metal surface.
• Do not install in areas with a direct heat
source.
• Do not install near any air discharge grill.
• Do not install in areas exposed to direct
sunlight.
• Ensure wall surface is at and clean.
• Install in a dry location away from water,
moisture, or rain.
Sensor Placement
Figure 20 shows suggested placement guidelines to
optimize detection zones.
Figure 19: Wall Mounted
Motion Sensor
Motion
Sensor
Motion
Sensor
Figure 20: Wall Mounted Motion Sensor Coverage Area
