LG OM4560 - General Specifications

Appendix
36
Appendix
5
General specifications
General
Power requirements Refer to the main label.
Power consumption
Refer to the main label.
Networked standby : 0.5 W
(If all network ports are activated.)
Dimensions (W x H x D)
Approx. 451.5 mm x 311 mm x 302.5 mm
(17.8 inch x 12.2 inch x 11.9 inch)
Net Weight (Approx.) Approx. 7.5 kg (16.5 lb)
Operating temperature 5 °C to 35 °C (41 °F to 95 °F)
Operating humidity 5 % to 90 %
Inputs / Outputs
Analog audio in (AUX IN) 2.0 Vrms (1 kHz, 0 dB), 600
Ω
, RCA jack (L, R)
Analog audio out (AUX OUT) 2.0 Vrms (1 kHz, 0 dB), 600
Ω
, RCA jack (L, R)
Microphone Sensitivity 15 mV (1 kHz), 6.3 mm jack x 1
Tuner
FM Tuning Range 87.5 to 108.0 MHz or 87.50 to 108.00 MHz
Amplier (RMS Output power)
Total 220 W x 1 (3
Ω
at 1 kHz, 20 % THD)
System
Frequency Response 80 Hz to 20 kHz
Signal-to-noise ratio More than 75 dB (1 kHz)
Dynamic range More than 80 dB
Bus Power Supply (USB) 5 V
0
500 mA
y
Design and specications are subject to change without notice.
