LG OM7550D - General Specifications

Appendix
47
Appendix
6
General specifications
General
Power requirements Refer to the main label.
Power consumption
Refer to the main label.
Networked standby : 0.4 W
(If all network ports are activated.)
Dimensions (W x H x D) 430 mm x 665 mm x 468 mm
Net Weight (Approx.) 22.7 kg
Operating temperature 5 °C to 35 °C (41 °F to 95 °F)
Operating humidity 60 %
Bus Power Supply (USB) 5 V
0
500 mA
Inputs / Outputs
HDMI OUT (video/audio) 19 pin (Type A, HDMI™ Connector )
AUX OUT 2.0 Vrms (1 kHz, 0 dB), 600 Ω, RCA jack (L, R)
AUX IN 2.0 Vrms (1 kHz, 0 dB), 600 Ω, RCA jack (L, R)
PORT. IN 1.2 Vrms (3.5 Ø jack)
MIC 27 mV
Tuner
FM Tuning Range 87.5 to 108.0 MHz or 87.50 to 108.00 MHz
CD
Frequency Response 40 to 20000 Hz
Signal-to-noise ratio 75 dB
Dynamic range 80 dB
Amplier
Total output (RMS) 1000 W
FRONT (RMS) 500 W x 1 (6 Ω at 150 Hz)
MID (RMS) 500 W x 1 (6 Ω at 1 kHz)
THD 20 %
y
Design and specications are subject to change without notice.
