5 Appendix
Appendix32
Appendix
5
General specifications
General
Power requirements Refer to the main label on the unit.
Power consumption Refer to the main label on the unit.
Dimensions (W x H x D) Approx. 275 mm x 530 mm x 275 mm
Operating temperature 5 °C to 35 °C
Operating humidity 60 %
Inputs / Outputs
Analog audio in (AUX IN) 1.2 Vrms (1 kHz, -4 dB), RCA jack (L, R) .
Analog audio out (AUX OUT) 2.0 Vrms (1 kHz, 0 dB), RCA jack (L, R)
Microphone (MIC) Sensitivity 20 mV (1 kHz), 6.3 mm jack
System
Frequency Response 80 to 20,000 Hz
Signal-to-noise ratio More than 75 dB
Dynamic range More than 80 dB
Bus Power Supply (USB)
5 V 0 500 mA
Amplier (RMS Output power)
Total output 150 W RMS
Front 75 W RMS × 2 (4 Ω at 1kHz, 20 % THD)
y Design and specications are subject to change without notice.
