LG S92T2-C Service Manual

2-119 2-120
Pin No. Vin1 VCC
IC150 TPS65252
8 Vin1 14.1
9 LX1 5.16
12 LX2 1.52
13 Vin2 14.1
27 USB_VIN 0
28 USB_VO 0
IC151 TJ3966
2 Vin 3.82
3 Vout 3.31
IC153 LM27152
2 Vin 6.12
4 Vout 5.05
IC154 LM37102
2 Vin 6.12
3 Vout 5.09
IC155 AOZ1051
2 Vin 14.15
9 Vout 1.23
IC702 LM37102
2 Vin 14.1
3 Vout 9.51
IC703 LM37102
2 Vin 14.1
3 Vout 5.12
IC803 AZ1117
3 Vin 3.32
2 Vout 1.81
IC810 AZ1117
3 Vin 3.32
2 Vout 1.81
IC701 TPIC2050
3 P12V_3 12.2
24 A9P5V 9.51
42 P12V_1 12.2
46 P12V_2 12.2
56 P5V_2 5.104
CIRCUIT VOLTAGE CHART
MEMO
