LG SPH7B-W - Circuit Voltage Chart; Ics

3-523-51
Location/ Name IC Name/ Type Vcc/ Vdd
IC100
MICOM
R5F100GHAFB#V0
TYPE: 48P
VENDER: RENESAS
VDD: 48
• Spec:
VDD: +1.8V~+5.5V
• Measured Voltage:
VDD: +3.418v
IC101
Serial Flash
W25Q80DVSSIG
TYPE: 8P
VENDER: MACRONIX
VCC:8
• Spec:
VCC: +2.7~+3.6V
• Measured Voltage:
VCC: +3.409V
IC200
A/D Converter
PCM1808
TYPE: 14P
VENDER: TI
VCC: 3
VDD: 4
VREF:1
• Spec:
VCC: +4.5V~+5.5V
VDD: +2.7V~+3.6V
• Measured Voltage:
VCC: +5.016V
VDD: +3.386V
VREF: +2.527V
IC300
DC,DC
SN1501019
TYPE: 6P
VENDER: TI
VIN: 3
VFB: 4
VBST: 6
• Spec:
VIN: +4.5V~+17V
VFB: -0.1V~5.5V
VBST: -0.1V~23V
• Measured Voltage:
VIN: +12.11V
VFB: +0.767V
VBST: +10.23V
IC301
DC,DC
SN1501019
TYPE: 6P
VENDER: TI
VIN: 3
VFB: 4
VBST: 6
• Spec:
VIN: +4.5V~+17V
VFB: -0.1V~5.5V
VBST: -0.1V~23V
• Measured Voltage:
VIN: +12.08V
VFB: +0.761V
VBST: +9.42V
IC302
DC,DC
MP9942
TYPE: 8P
VENDER: MPS
VCC: 7
• Spec:
VCC:+4.6V~+5.2V
• Measured Voltage:
VCC: +4.75V
IC303
DC,DC
SN1501019
TYPE: 6P
VENDER: TI
VIN: 3
VFB: 4
VBST: 6
• Spec:
VIN: +4.5V~+17V
VFB: -0.1V~5.5V
VBST: -0.1V~23V
• Measured Voltage:
VIN: +12.08V
VFB: +0.777V
VBST: +10.21V
IC304
DC,DC
TJ2242
TYPE: 6P
VENDER: HTC
VIN: 1
VOUT: 6
• Spec:
VIN: +2.8V~+5.5V
VOUT: ~+6.5V
• Measured Voltage:
VIN: +3.41V
VOUT: +3.43V
IC305
DC,DC
TJ2242
TYPE: 6P
VENDER: HTC
VIN: 1
VOUT: 6
• Spec:
VIN: +2.8V~+5.5V
VOUT: ~+6.5V
• Measured Voltage:
VIN: +3.40V
VOUT: +3.42V
IC306
DC,DC
TJ2242
TYPE: 6P
VENDER: HTC
VIN: 1
VOUT: 6
• Spec:
VIN: +2.8V~+5.5V
VOUT: ~+6.5V
• Measured Voltage:
VIN: +4.95V
VOUT: +4.90V
Location/ Name IC Name/ Type Vcc/ Vdd
IC600
PWM
PS9870
TYPE:
VENDER:
VDD_IO: 6,31,38
VIN33: 23
VIN33_PLL: 45
VDD_CORE: 2,10,30, 40
VDD_PLL: 47
• Spec:
VDD_IO:
+2.97V~+3.63V
VIN33: +2.97V~+3.63V
VIN33_PLL:
+2.97V~+3.63V
VDD_CORE:
+1.08V~+1.32V
VDD_PLL:
+1.08V~+1.32V
• Measured Voltage:
VDD_IO: +3.342V
VIN33:+3.362V
VIN33_PLL: +3.359V
VDD_CORE: +1.241V
VDD_PLL: +1.259V
IC700
AMP
TAS5612LADDVR
TYPE: 44P
VENDER: TI
GVDD_AB: 1
GVDD_CD: 22
PVDD_AB: 36,37,38
PVDD_CD: 29,30,31
VDD: 2
DVDD: 8
AVDD: 13
• Spec:
GVDD_AB: -0,3V~13.2V
GVDD_CD: -0,3V~13.2V
PVDD_AB: -0.3V~50V
PVDD_CD: -0.3V~50V
VDD: -0,3V~13.2V
DVDD: -0.3V~4.2V
AVDD: -0.3V~8.5V
• Measured Voltage:
GVDD_AB: +11.92V
GVDD_CD: +11.93V
PVDD_AB: +25.30V
PVDD_CD: +25.29V
VDD:+11.92V
DVDD: +3.289V
AVDD: +7.695V
IC701
AMP
TAS5612LADDVR
TYPE: 44P
VENDER: TI
GVDD_AB: 1
GVDD_CD: 22
PVDD_AB: 36,37,38
PVDD_CD: 29,30,31
VDD: 2
DVDD: 8
AVDD: 13
• Spec:
GVDD_AB: -0,3V~13.2V
GVDD_CD: -0,3V~13.2V
PVDD_AB: -0.3V~50V
PVDD_CD: -0.3V~50V
VDD: -0,3V~13.2V
DVDD: -0.3V~4.2V
AVDD: -0.3V~8.5V
• Measured Voltage:
GVDD_AB: +11.92V
GVDD_CD: +11.92V
PVDD_AB: +25.27V
PVDD_CD: +25.27V
VDD:+11.92V
DVDD: +3.35V
AVDD: +7.62V
Location/ Name IC Name/ Type Vcc/ Vdd
IC307
Serial Flash
SN1501019
TYPE: 6P
VENDER: TI
VIN: 3
VFB: 4
VBST: 6
• Spec:
VIN: +4.5V~+17V
VFB: -0.1V~5.5V
VBST: -0.1V~23V
• Measured Voltage:
VIN: +12.06V
VFB: +0.790V
VBST: +7.56V
IC501
MPEG
MT8506ODAG
TYPE: 589P
VENDER: MEDIATEKC
DVCC12:J11,J12,J14,
J15,J17,J18,J19,K11,K12
K14,K15,K17,K18,K19,
L10L19,M10,M19,N10,
N19P10, P19,P20,R10,
R20,T10,T19,T20,U10,
U20,V11,V18,V20,W10,
W11,W12,W13,W14,
W15,W16,W18,W19
DVCC33: G14,H14,G8,H8
U21,V21,F23,G22,AE19,
AE20
AVDD12:
AB21,H25,G26,J25,H26,
E23,C15,G11
AVDD33: AC5,AD20,F2
6,D26,E26,R25,Y26,AA2
4,AA25,T27,V22,F18,E1
8,G12
DDRVCCIO1:H5,H6,K5,
L5,M3,M8,N7,P8,R7,T8,
U7,W3,W8,Y7,AA17,AB3
AB11,AB13,AB17,AC3
AC11,AC14,AC19,AD19,A
E5,AF7,AF10,AF17,AF18
DDRVREF: N8
EFPWRQ(E-fuse):H1
• Spec:
DVCC12: 1.14V~1.26V
DVCC33: 3.15V~3.45V
AVDD12: 1.14V~1.26V
AVDD33: 3.15V~3.45V
DDRVCCIO1:
1.425V~1.575V
DDRVREF: 0.775V
• Measured Voltage:
DVCC12:+1.217V
DVCC33: +3.360V
AVDD12:+1.218V
AVDD33:+3.360V
DDRVCCIO1: +1.522V
DDRVREF:+0.796V
IC503
DDR3 SDRAM
K4B1G1646G-BCMA
TYPE:
VENDER: SAMSUNG
VDD: B2,D9,G7,K2,K8,
N1,N9,R1,R9
VDDQ:
A1,A8,C1,C9,D2,E9,F1,
H2,H9
• Spec:
VDD: +1.425V~+1.575
VDDQ: +1.425V~+1.575
• Measured Voltage:
VDD:+1.522V
VDDQ:+1.528V
IC504
DDR3 SDRAM
K4B1G1646G-BCMA
TYPE:
VENDER: SAMSUNG
VDD: B2,D9,G7,K2,K8,
N1,N9,R1,R9
VDDQ:
A1,A8,C1,C9,D2,E9,F1,
H2,H9
• Spec:
VDD: +1.425V~+1.575
VDDQ: +1.425V~+1.575
• Measured Voltage:
VDD:+1.522V
VDDQ:+1.528V
IC505
NAND
S34ML04G200TFI000
TYPE: 48P
VENDER:SPANSION
VCC: 12,34,37
• Spec:
VCC: -0.6 to +4.6
• Measured Voltage:
VCC: +3.362V
CIRCUIT VOLTAGE CHART
1. ICs
