LG UP970 - Specifications

Appendix 57
Appendix
6
Specifications
General
Power requirements Refer to main label.
Power consumption Refer to main label.
Dimensions (W x H x D)
Approx. 430 mm x 45.5 mm x 205 mm
(16.9 inches x 1.7 inches x 8.0 inches)
Operating temperature 41 °F - 95 °F
Operating humidity 5 % - 90 %
Outputs
HDMI out (Video/ Audio)
(HDMI1 OUT TO TV)
19 pin (Type A, HDMI™ Connector) x 1
HDMI out (Audio)
(HDMI2 AUDIO ONLY)
19 pin (Type A, HDMI™ Connector) x 1
Digital audio out
(OPTICAL AUDIO OUT)
3 V (p-p), Optical jack x 1
System
Laser Semiconductor laser
wavelength 405 nm / 650 nm
Signal system Standard NTSC Color TV system
LAN port Ethernet jack x 1, 10BASE-T / 100BASE-TX
Wireless LAN (internal antenna)
Integrated IEEE 802.11n/ac (5 GHz and 2.4 GHz bands) wireless
networking access, compatible with 802.11b/g/n/ac Wi-Fi networks.
Bus Power Supply (USB)
5 V 0 500 mA
y Design and specications are subject to change without notice.
