LG W2242 KT Series User Manual

A8
Control Function
Control Panel Functions
MENU Button
Use this button to enter or exit the On Screen Display.
OSD LOCKED/UNLOCKED
This function allows you to lock the current control
settings, so that they cannot be inadvertently changed.
Press and hold the MENU button for several seconds.
The message "OSD LOCKED" should appear.
You can unlock the OSD controls at any time by pushing
the MENU button for several seconds. The message
"OSD UNLOCKED" should appear.
Front Panel Controls
SOURCE Button
Use this button to enter or exit the On Screen Display.
Use this button to make D-Sub or DVI connector
active. This feature is used when two computers are
connected to the display. The default setting is D-Sub.

LG W2242 KT Series Specifications

General

Screen Size	22 inches
Resolution	1680 x 1050
Aspect Ratio	16:10
Brightness	300 cd/m²
Contrast Ratio	1000:1
Response Time	5 ms
Panel Type	TN
Inputs	DVI
Power Consumption	45W (typical)
Viewing Angle	170°/160°
