LG W2242T User Manual

Troubleshooting
Display image is incorrect
● Display Position is
incorrect.
● On the screen
background, vertical
bars or stripes are
visible.
● Any horizontal noise
appearing in any
image or characters
are not clearly
portrayed.
•
Press the AUTO/SET button to automatically
adjust your display image to the ideal setting.
If the results are unsatisfactory, adjust the image
position using the H position and V position icon
in the on screen display.
• Press the AUTO/SET button to automatically
adjust your display image to the ideal setting.
If the results are unsatisfactory, decrease the
vertical bars or stripes using the CLOCK icon in
the on screen display.
• Press the AUTO/SET button to automatically
adjust your display image to the ideal setting.
If the results are unsatisfactory, decrease the
horizontal bars using the PHASE icon in the on
screen display.
• Check Control Panel --> Display --> Settings
and adjust the display to the recommended
resolution or adjust the display image to the ideal
setting. Set the color setting higher than 24 bits
(true color).
Important
Check Control Panel --> Display --> Settings and see if the frequency or the
resolution were changed. If yes, readjust the video card to the recommend
resolution.
The setting method can differ by computer and O/S (Operation System),
and resolution mentioned above may not be supported by the video card
performance. In this case, please ask to the computer or the video card
manufacturer.
A17

LG W2242T Specifications

General

Pixel pitch	0.282 x 0.282 mm
Aspect ratio	16:10
Display diagonal	22 \
Display resolution	1680 x 1050 pixels
Vertical scan range	56 - 75 Hz
Horizontal scan range	30 - 83 kHz
Contrast ratio (typical)	-
Display brightness (typical)	250 cd/m²
Special features	sRGB, HDCP, Flatron f Engine, Intelligent Auto, Auto resolution, 4:3 in Wide (ARC)
Power requirements	90 – 264 Vac, 47 – 63 Hz
Display viewable area (HxV)	473.86 x 296.16 mm
HDCP	Yes
Certification	TÜV-Typ, CE, EPA Energy Star, UL, CSA, SEMKO, FCC-B, TCO03
Product color	Black
Compliance industry standards	DDC 2B
LED indicators	Stand-by
Tilt angle range	-5 - 20 °
Panel mounting interface	75 x 75 mm
Power consumption (standby)	0.3 W
Power consumption (typical)	22 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (with stand)	210 mm
Height (with stand)	418 mm
Weight (with stand)	4700 g
Depth (without stand)	63 mm
Width (without stand)	516 mm
Height (without stand)	346 mm
