LG WD-10480T User Manual

14
7-5.ERROR DISPLAY.
ERROR SYMPTOM CAUSE
1
WATER INLET
Water has not reached to the pre-set level within 4 min. since
ERROR
inlet valve operated, or water has not reached to the normal
level within 25 min.
2
IMBALANCE
The appliance is tilted.
ERROR
Laundry is gathered to one side.
Non distributable things are put into the drum.
3 DRAIN ERROR Water has not drained enough within 5 min.
4
OVERFLOW Water is automatically being pumped out because too much
ERROR
water is in the tub.
5
SENSOR PRESSURE
The sensor pressure switch is out of order.
S/W ERROR
6
DOOR OPEN The
[Start/Pause] button is pressed with the door open.
ERROR
The door switch is out of order.
7
HEATING
ERROR
The thermistor is out of order
.
If you press the
¥
¥
[Start/Pause]
button when an error is displayed, any error except S/W ERROR will disappear
and the machine will change into pause status.
In case of if the error is not resolved within 20 sec. In the case of other
errors, if the error is not resolved within 4 min. power will be turned off automatically and the error code will be
blinked. But in case of , power will not be turned off.
,,,
Downloaded From WashingMachine-Manual.com Manuals

LG WD-10480T Specifications

General

Power consumption (typical)	2100 W
Water consumption per cycle	69 L
Energy consumption washing per cycle	1.2 kWh
Display type	LED
Loading type	Front-load
Product color	White
Door opening angle	180 °
Appliance placement	Freestanding
Washing class	A
Power requirements	AC 220 - 240V, 50Hz
Drum capacity	7 kg
Delay start (max)	19 h
Spin-drying class	B
Maximum spin speed	1000 RPM
Delayed start timer	Yes
Number of washing programs	16

Weight and Dimensions

Depth	550 mm
Width	600 mm
Height	842 mm
Weight	65000 g
